Clean room
GINYS-IFAE-001
White Room for Detector / Chip Packaging
The IFAE's chip packaging room allows all the necessary operations to be carried out to produce detectors and to attach them to the necessary reading chips or electronic boards. The clean room is made up of three areas with different qualities: two of about 12 m2 of class 1000 and 10000, respectively, and another of about 20 m2 of class 100000.
Laboratory to test newly constructed instruments before sending them to experimental sites (CERN, ORM, JPARC, CTIO, EGO, etc.)
Equipment
The rooms are equipped with a welding ball deposition machine (Pactech SB2SM), a wire bonding machine (Delvotec 64000G5), a bump-bonding machine (FC-150), two digital microscopes, a “Bond-tester” (Dage Optima 4000), an X-ray scanner (Dage XD7600NT Ruby), a reflow oven (ATV SRO700) and a “pick-and-place” machine with dispenser (Finetech FINEPLACER pico ma).
